Product Description
Multiport aluminum flat tube for heat exchanger
Aluminum tube has several advantages. First one is Welding technical advantages: suitable for industrial production of thin-walled copper and aluminum tubes welding technique, referred to as world-class problem, an air conditioner is the key technology of connecting aluminum and copper pipe. The second advantage in service life: From the perspective of the inner wall of the aluminum tube, since the refrigerant does not contain moisture, the inner wall of the copper-aluminum connecting tube will not corrode. The third one is Energy-saving advantage: The connection pipeline between the indoor unit and the outdoor unit of the air conditioner, the lower the heat transfer efficiency, the more energy-saving, or in other words, the better the heat insulation effect, the more energy-saving. It has Excellent bending performance, easy to install and move the machine. Trumony supply good aluminum micro channel tube, aluminum grooved tube, aluminum cold drawn tube, aluminum extrusion sheet, aluminum rolling sheet and so on...
Company Introduction:
Trumony Aluminum Co.LTD build from 2006, hae export over 53 countries of worldwide. Our main products are aluminum alloy cladding material, cole material and other aluminum products like aluminum coil, aluminum foil, aluminum strip, oval flat aluminum tube, Multiport Aluminum Flat Tube , aluminum pipe, aluminum tube, multiport aluminum flat pipe , Aluminum flat tube for radiator etc, for automobile heat exchangers area such as radiator, intercooler, condenser, evaporator and industrial heat exchangers, like electricity power radiator, air conditioner etc.There are complete sets of modern production and testing equipment operation workshops for casting, hot rolling, cold rolling, finishing and advanced check-out forresearching and testing,such as WDW-3010- micro-controlled electronic universal testing machine,CALS-2000 aluminum alloy metallographic image analysis system etc.
1.Application:
1) car air conditioner
2) in the field of commercial:
such as household air conditioner, condenser, evaporator, fridge, oil cooler and inter cooler
2.Alloy States:
1) 1000 series:1050, 1060, 1100, 1197 etc
2) 3000 series:3102, 3003
3.Temper: O/F/H111/H112 etc
4.Mechanical Properties of Multiport aluminum flat tube for heat exchanger
|
No.
|
Alloy
|
Temper
|
Tensile Strength(Mpa)
|
Yield Strength(Mpa)
|
Elogation(%)
|
|
1
|
1050
|
O/F/H111/H112
|
≥ 65
|
≥ 20
|
≥ 25
|
|
2
|
1100
|
O/F/H111/H112
|
≥ 75
|
≥ 20
|
≥ 25
|
|
3
|
1197
|
O/F/H111/H112
|
≥ 80
|
≥ 25
|
≥ 20
|
|
4
|
3102
|
O/F/H111/H112
|
≥ 75
|
≥ 20
|
≥ 25
|
|
5
|
3R03
|
O/F/H111/H112
|
≥ 80
|
≥ 25
|
≥ 20
|
5.Chemical Composition
|
No.
|
Alloy
|
Si
|
Fe
|
Cu
|
Mn
|
Mg
|
Cr
|
Zn
|
V
|
Ti
|
|
1
|
1050
|
≤ 0.25
|
≤ 0.40
|
≤ 0.05
|
≤ 0.05
|
≤ 0.05
|
-
|
≤ 0.05
|
≤ 0.05
|
≤ 0.03
|
|
2
|
1100
|
≤ 0.95(Fe+Si)
|
0.05-0.20
|
≤ 0.05
|
-
|
-
|
≤ 0.10
|
-
|
-
|
|
3
|
1197
|
≤ 0.15
|
≤ 0.20
|
0.40-0.55
|
0.10-0.20
|
≤ 0.03
|
≤ 0.05
|
≤ 0.05
|
≤ 0.05
|
≤ 0.05
|
|
4
|
3102
|
≤ 0.40
|
≤ 0.70
|
≤ 0.10
|
0.05-0.40
|
-
|
-
|
≤ 0.30
|
-
|
≤ 0.10
|
|
5
|
3R03
|
≤ 0.15
|
≤ 0.15
|
≤ 0.01
|
0.90-1.10
|
≤ 0.03
|
≤ 0.03
|
≤ 0.05
|
≤ 0.05
|
≤ 0.05
|
6. Size Tolerance
|
Width
|
Thickness
|
Wall Thickness
|
Length
|
Lateral Curvature
|
Frontal Curvature
|
Twsiting Dgree
|
|
± 0.05mm
|
± 0.03mm
|
± 0.05mm
|
± 0.03mm
|
≤ L× 0.2%
|
≤ L× 0.25%
|
≤ L× 0.15%
|
7.Our products will be tested in strict standard before delivery, some data for your reference.
|
No
|
Products' Testing Name
|
Contents and requests
|
|
1
|
Corrosion Resistance
|
Salt spray test: ≥ 750 hours
|
|
2
|
Zn Coating Standards
|
6/8/10/13± 2g/square meter
|
|
3
|
Flux Cotaing Standards
|
10-15± 2g/square meter
|
8.Commercial terms
|
Minimum Order Quantity:
|
5 metric tons
|
|
Price:
|
negotiation
|
|
Payment Terms:
|
T/T or LC
|
|
Supply Ability:
|
100,000 mt per month
|
|
Delivery Time:
|
15-30 working days after received your down payment
|
|
Packaging Details:
|
Standard export packaging
|
Multiport aluminum flat tube for heat exchanger is widely used for manufacturing of various kinds of heat exchangers:
Air conditioning
Engine cooling
Condensers
Evaporators
Radiators
Heater cores
Charge air coolers/intercoolers
Engine oil coolers/transmission oil coolers
Our advantage:
1. Since 2006, we have rich experience in this industry in China;
2. Good reputation in aluminum material industry;
3. We have our own development department for new material research;
4. Good experience and cooperation with big client in the world;
5. With Certificate ISO9001-2008;
6. High performance cost ratio;
7. Fast delivery time;
8. Good communication skills, and good after sells service, and understandings for customers;
FAQ
1, Q: Are you manufacturer of Multiport aluminum flat tube for heat exchanger?
A: Yes, we are established in 2006. As a manufacturer our customers are welcome to visit our factory.
2, Q: Do you accept customized orders?
A: Yes, we do. Your customized orders are always welcomed. Please kindly offer us your technical perfrmances or samples so that we can customize the products according to your preferences. About any further detail, please feel free to contact us.
3. Q: How can I get one quotation faster?
A: Pls offer details about your demands as more as possible,insulation thickness,over diameter,nominal voltage,working temperature,color,quantity,application,etc.
4. Q: If I can not offer above information,what should I do?
A: Try your best to offer more information,we will help you design suitable wires&cables.
5. Q: What is your company sample policy?
A: As one supplier,we see that sample is necessary for our both sides,our policy is to offer free sample as possible as we can,just one situation is exception,sample is with very complex structure,besides,we have no it in stock.
About sample shippment,you need to pay for the freight,usually freight collect by express.
6. Q: What is the lead time of sample?
A: There are several different situations:
Immediately when you need it if we have it in stock;
5~15days if no stocked sample and the sample structure is not complex;
15~30days if no stocked sample and the sample is with complex structure.
